Genset Silent TDG 11000 SDV 8000 Watt Dual Voltage 1 Phase 3 Phase

Silent Diesel Generator 10 KVA – 11 KVA Dual Voltage – Panel Digital – Heavy Duty

Brand: TSUZUMI
Type : TDG 11000 SDV (Model Capsule Kubaoya Style)
Frequency (hz): 50
Rated power (kva/kw): 10/8
Maks power (kva/kw): 11/8
Rated voltage (a.c) (v): 380/220
Rated current (a.c) (a): 11.4/34
Power factor : 0.8
Phase: one
Pole: 1
Excitation way: Self – Exciting and Voltage – Constant with AVR
Engine Bore x stroke (mm): 98×84
Total Displacement (ml): 633
Cooling System: Forced Cooling
Lube Oil Capacity (L): 1.65
Starting System: Electric
Fuel: Diesel
Panel Type: Digital with Module (AMF built in)
Structure Type: Silent Capsule Basic Model Kubaoya Style
Noise (10m) dB: 72-75
Capacity of fuel tank (L): 30
Working Time at Fuel tank (h): 12
Gross weight (kg): 250
Dimension (mm) (L x w x h): 1130x760x860

Keunggulan produk :
– Struktur Silent Basic model (kapsul Kubaoya Style) membuat genset kuat dan kokoh
– Sound absorbing foam, suara lebih redam
– Panel Digital memudahkan pengecekan status genset saat load beban, servis & pergantian oli (Ampere,Kw,Volt, Hz, Time work )
– Support pemasangan panel otomatis (ATS) PLN – Genset
