Mesin Pemadat Aspal Stamper Kodok TC88 + Engine TX 200

Spesifikasi :
Model : TC88
Weight : 88.5 Kg
Power : 3.6 Kw
Frequency : 4200 vpm
Centrifugal Force : 15 kN
Compaction Depth : 30 cm
Speed : 38 cm/s
Manual.Yr : 2023

Jika mengunakan engine TX 200

Merek : Tsuzumi
Model : TX200
Bore X Stroke : 68 X 54 mm
Displacement : 196 cc
Compression Ratio : 8.7 : 1
Net Power (Kw/Rpm) : 4.1/3600
Net Torque (N.m/Rpm) : 11/2500
PTO Shaft Rotation : Berlawanan Jarum Jam
Ignition system : Pengapian Magneto Transistorized
Lubrication System : Percikan Paksa
Carburetor : Karburator Katup hisap Datar
Gorvernor System : Mekanik Sentrifugal
Engine Type : Pendingin Udara Paksa 4 tak OHV
Starting System : Recoil/Stater Elektrik
Fuel Tank Capacity : 3.6 L
Engine Oil Capacity : 0.55 L
Fuel Consumtion (g/Kw.h) : <380
Dimension ( L x W x H mm) : 390 X 320 X 345
Net Weight : 17 Kg
